    Replaceable Hepa Filter Ceiling Hepa Diffusers stainless steel

    Ask Lasest Price
    Brand Name : YN
    Model Number : YN-HU-870
    Certification : CE/ISO
    Price : reconsideration
    Payment Terms : L/C, D/A, T/T, Western Union
    Supply Ability : 10000PCS/month
    Delivery Time : 7-15 work days
    • Product Details
    • Company Profile

    Replaceable Hepa Filter Ceiling Hepa Diffusers stainless steel

    Replaceable hepa filter ceiling hepa supply diffusers with hasp for cleanroom

    1. Hepa supply diffusers description

    Material and Operation Conditions

    MediaDomestic Glass fiber HV Glass fiber
    SealantPU Polyurethane
    CabinetAluminum/Galvanized/Stainless steel
    SeparatorEVA hot melt adhesive
    GasketPU Polyurethane, EVA, Neoprene

    Filter Efficiency

    (EN1822)

    H13:99.97-99.99% 0.3μm

    H14:99.995-99.999% 0.3μm

    Max. Temperature70℃
    Max. HumidityDomestic Glass fiber: 80% HV Glass fiber: 100%


    Product Introduction


    Disposable HEPA filter with Hood is terminal filter for a variety of filtration systems, closed structure to prevent internal voids and leaks. Anodized aluminum casing quality, light weight, can full stick PEF cotton insulation. Include air input duct with optional diameter Φ250, Φ30, Φ350. Each filter has been strictly tested before factory.
    Features: Strong ventilation, good looks, easy installation, Good sealing performance, light weight, high filtration efficiency.
    Applications: Operating room, laboratory, pharmacy, microelectronics, film, optical equipment and food processing plants and other which demand high clean class level work environment.


    2.Hepa supply diffusers structure

    1). The Gel Seal filters are available in HEPA or ULPA efficiencies.

    2). The dimple pleated filter pack is sealed in an anodized aluminum frame that contains a gelled channel to insure a leak free, tight seal.

    3). The filter element is protected by an anodized aluminum housing and diffuser screen, with a damper control and challenge port for the measurement of challenged aerosol.

    4). An anodized extruded aluminum center divider with access port provides access for adjustment of the distribution plate and measurement of the resistance and challenge aerosol.

    5). A painted expanded metal faceguard on the downstream side protects the media.

    3. Standard Model Technology Parameter

    HEPA DIFFUSER DATA SHEET
    Filter sizeBox size (top blow)Box size (side blow)Rated air flowSize of round interfaceSize of square interfaceFilter resistance
    L*W*H(mm)L*W*H(mm)L*W*H(mm)m³/hmmmmH13 (Pa)H14 (Pa)
    340*340*70410*410*280410*410*450500250200*200280300
    340*340*90410*410*300410*410*450250270
    484*484*70554*554*280554*554*4501000300300*200280300
    484*484*90554*554*300554*554*450250270
    610*610*70680*680*280680*680*4501500350400*200280300
    610*610*90680*680*300680*680*450250270
    870*570*70940*640*280940*640*4502000350500*200249280
    870*570*90940*640*300940*640*450220250
    1170*570*701240*640*2801240*640*4502500ø300*2units ø450*1unit630*200249280
    1170*570*901240*640*3001240*640*450220250
    1260*610*701290*640*2801290*680*4503000ø300*2units ø450*1unit630*250249280
    1260*610*901290*640*3001290*680*450220250
    Note:SIDE BLOW ONLY MATCH SQUARE INTERFACE
    Filter resistance common difference is ±10%
